Refrigerated Bath Circulator


The Refrigerated Bath Circulator RS10S is designed to maintain the realization of constant temperature conditions. The bath is equipped with powerful ecofriendly compressors using CFC free gases viz R134a as
the refrigerant. As it is intended for temperature control of external, closed circuits, it is thus equipped with the powerful pumps. All parts which come into contact with the heat transfer liquid are made from stainless steel or high-quality polymer. This bath have a built in drain at the rear side to enable smooth and efficient cleaning. The tanks are made of 304 SS
and are deep drawn.

Technical Specifications:-

Working Temperature Range: -10…100  C

Temperature Controller: PID

Temperature Stability: 0.04 +/- O C

Display: LED

Display Resolution: 0.1 C

Heater Capacity at 230 V: 2000 Watts

Cooling Capacity @20 O C: 280 Watts

Pump Flow Rate: 12.5 Lpm

Bath Volume: 5 Liters

Supply Voltage: 230 / 50 Volts / Hz

Additional information

12x12x15 cms (WxLxD)

Download PDF
Category: Accessories
